Products range extended with Vector Network Analyzer Bode 100

Vector Network Analyzer Bode 100

The solution for your measurement tasks from 1 Hz to 40 MHz

Bode 100

The Bode 100 consists of hardware and software. The high quality hardware ensures accurate measurement results in the wide frequency range from 1 Hz to 40 MHz. Its portable and compact design enables you to test wherever you want. Due to the versatile system design, the Bode 100 works as three devices in one:

1. Vector Network Analyzer

The vector network analyzer function of the Bode 100 allows you to measure:

• Swept S-parameters in the 50Ω system
• Reflection coefcient and return loss
• Insertion loss of filters
• Group delay characteristics
• Influence of termination on amplifiers

2. Frequency Response Analyzer

The Bode 100 serves as a Gain/Phase meter and is ideally suited to measure:

• Transfer functions of electronic circuits

• Stability of control systems such as DC/DCconverters
• Power Supply Rejection Ratio (PSRR) respectively Audio Suspectibility

3. Impedance Analyzer

The Bode 100 o ers you a high variety of impedance measurement possibilities to

easily analyze:

• Electromagnetic devices such as transformers and inductors
• Capacitors and their parasitics
• Ultrasonic and piezo electric components or systems
• Very high Q-circuits such as quartz cristals and oscillators
• Input- and output impedance of electronic circuits

More information below.
